​ 我们的数据挖掘平台对数据统计有比较迫切的需求，而Spark本身对数据统计已经做了一些工作，希望梳理一下Spark已经支持的数据统计功能，后期再进行扩展。

# 准备数据

在参考文献6中下载[鸢尾花数据](https://archive.ics.uci.edu/ml/machine-learning-databases/iris/)，此处格式为iris.data格式，**先将data后缀改为csv后缀（不影响使用，只是为了保证后续操作不需要修改）**。

数据格式如下：

| SepalLength | SepalWidth | PetalLength | PetalWidth | Name |
| ———– | ———- | ———– | ———- | ———– |
| 5.1 | 3.5 | 1.4 | 0.2 | Iris-setosa |
| 4.9 | 3 | 1.4 | 0.2 | Iris-setosa |
| 4.7 | 3.2 | 1.3 | 0.2 | Iris-setosa |
| 4.6 | 3.1 | 1.5 | 0.2 | Iris-setosa |
| 5 | 3.6 | 1.4 | 0.2 | Iris-setosa |
| 5.4 | 3.9 | 1.7 | 0.4 | Iris-setosa |
| 4.6 | 3.4 | 1.4 | 0.3 | Iris-setosa |

数据说明见附录中的`鸢尾花数据`。

我们先把数据放到Spark sql数仓中

“`sql
CREATE TABLE IF NOT EXISTS iris ( SepalLength FLOAT , SepalWidth FLOAT
, PetalLength FLOAT , PetalWidth FLOAT
, Species VARCHAR(100)
)
ROW FORMAT DELIMITED
FIELDS TERMINATED BY ‘,’
STORED AS TEXTFILE
LOCATION ‘/mnt/disk1/starqiu/iris’;
“`

# 表的分析与统计

Analyze Table语法如下：

“`sql
ANALYZE TABLE [db_name.]table_name COMPUTE STATISTICS [analyze_option]
“`

> Collect statistics about the table that can be used by the query optimizer to find a better plan.

可以看到Spark表的分析可以**为spark sql做查询优化**，以便得到更好的查询性能。Spark Sql默认使用CBO（基于代价的优化），这在多表join查询时尤其有用。

此处的`analyze_option`参数主要分为两类，表统计和列统计。

## 表统计

表的基本统计信息一般包括记录总数和所占空间。

Table statistics用法如下：

“`sql
ANALYZE TABLE [db_name.]table_name COMPUTE STATISTICS [NOSCAN]
“`

> Collect only basic statistics for the table (number of rows, size in bytes).
>
> **NOSCAN**
> Collect only statistics that do not require scanning the whole table (that is, size in bytes).

运行命令`ANALYZE TABLE iris COMPUTE STATISTICS;`可以得到表的记录总数和所占空间大小。如果不想全表扫描，加上`NOSCAN`关键字，不会全表扫描，但只能得到所占空间大小。

表统计信息的描述命令语法如下：

“`sql
DESCRIBE [EXTENDED] [db_name.]table_name
“`

> Return the metadata of an existing table (column names, data types, and comments). If the table does not exist, an exception is thrown.
>
> **EXTENDED**
> Display detailed information about the table, including parent database, table type, storage information, and properties.
> Describe Partition

运行`DESCRIBE EXTENDED iris;`，结果如下：

“`shell
spark-sql> DESCRIBE EXTENDED iris;
SepalLength float NULL
SepalWidth float NULL
PetalLength float NULL
PetalWidth float NULL
Species string NULL

# Detailed Table Information CatalogTable(
Table: `default`.`iris`
Owner: root
Created: Sat Feb 16 17:24:32 CST 2019
Last Access: Thu Jan 01 08:00:00 CST 1970
Type: EXTERNAL
Schema: [StructField(SepalLength,FloatType,true), StructField(SepalWidth,FloatType,true), StructField(PetalLength,FloatType,true), StructField(PetalWidth,FloatType,true), StructField(Species,StringType,true)]
Provider: hive
Properties: [rawDataSize=-1, numFiles=0, transient_lastDdlTime=1550311815, totalSize=0, COLUMN_STATS_ACCURATE=false, numRows=-1]
Statistics: sizeInBytes=3808, rowCount=150, isBroadcastable=false
Storage(Location: hdfs://data126:8020/mnt/disk1/starqiu/iris, InputFormat: org.apache.hadoop.mapred.TextInputFormat, OutputFormat: org.apache.hadoop.hive.ql.io.HiveIgnoreKeyTextOutputFormat, Serde: org.apache.hadoop.hive.serde2.lazy.LazySimpleSerDe, Properties: [field.delim=,, serialization.format=,])
Partition Provider: Catalog)
Time taken: 0.112 seconds, Fetched 7 row(s)

“`

通过`Statistics:`可以看到表的记录总数是150条，所占空间3808B，约4KB。

## 列统计

Column statistics用法如下：

“`sql
ANALYZE TABLE [db_name.]table_name COMPUTE STATISTICS FOR COLUMNS col1 [, col2, …]
“`

> Collect column statistics for the specified columns in addition to table statistics.
>
> Tip
>
> Use this command whenever possible because it collects more statistics so the optimizer can find better plans. Make sure to collect statistics for all columns used by the query.

列统计的描述命令语法如下：

“`sql
DESCRIBE [EXTENDED][db_name.]table_name column_name

New in version runtime-3.3.
“`

> EXTENDED
> Display detailed information about the specified columns, including the column statistics collected by the command ANALYZE TABLE table_name COMPUTE STATISTICS FOR COLUMNS column_name [column_name, …].

需要注意的是这个功能在runtime-3.3版本才有的特性，而runtime-3.3封装的是Spark 2.2，会详见文末附录的`databricks Runtime版本与Spark版本的对应关系`

运行命令`ANALYZE TABLE iris COMPUTE STATISTICS FOR COLUMNS SepalLength, SepalWidth, PetalLength, PetalWidth, Species;`计算指定多列的统计信息，

运行`DESCRIBE EXTENDED iris SepalLength;`获取指定一列的统计信息，结果如下：

“`shell
spark-sql> ANALYZE TABLE iris COMPUTE STATISTICS FOR COLUMNS SepalLength, SepalWidth, PetalLength, PetalWidth, Species;
Time taken: 4.45 seconds
spark-sql> DESCRIBE EXTENDED iris PetalWidth;
col_name PetalWidth
data_type float
comment NULL
min 0.10000000149011612
max 2.5
num_nulls 0
distinct_count 21
avg_col_len 4
max_col_len 4
histogram NULL
Time taken: 0.104 seconds, Fetched 10 row(s)
“`

目前测试Spark2.2.2不支持该语句，但是Spark2.4.0支持。如果不支持，则可以通过访问hive的元数据库也可以得到这些信息，sql语句如下：

“`sql
select param_key, param_value
from TABLE_PARAMS tp, TBLS t
where tp.tbl_id=t.tbl_id and tbl_name = ‘iris’
and param_key like ‘spark.sql.stat%’;
“`

以下是PetalWidth列的统计结果，可以看到包含**不重复的记录数，空值数，最大值、最小值，平均长度以及最大长度**

| param_key | param_value |
| —————————————————— | ——————- |
| spark.sql.statistics.colStats.PetalWidth.avgLen | 4 |
| spark.sql.statistics.colStats.PetalWidth.distinctCount | 21 |
| spark.sql.statistics.colStats.PetalWidth.max | 2.5 |
| spark.sql.statistics.colStats.PetalWidth.maxLen | 4 |
| spark.sql.statistics.colStats.PetalWidth.min | 0.10000000149011612 |
| spark.sql.statistics.colStats.PetalWidth.nullCount | 0 |
| spark.sql.statistics.colStats.PetalWidth.version | 1 |

# 总结

​ 可以看到这些统计信息不仅对了解数据质量非常有用，对使用Spark sql进行查询也能得到优化，进一步提升速度。后续再写一篇CBO如何利用这些信息进行优化。

​ 目前还不清楚Runtime中的Spark功能和开源版的有无差异，但Spark2.4支持表的分析统计操作，建议平台后续项目升级到Spark2.4 。

# 附录

## 鸢尾花数据说明

​ Iris数据集是常用的分类实验数据集，由Fisher, 1936收集整理。Iris也称鸢尾花卉数据集，是一类多重变量分析的数据集。数据集包含150个数据集，分为3类，每类50个数据，每个数据包含4个属性。iris以鸢尾花的特征作为数据来源，常用在分类操作中。该数据集由3种不同类型的鸢尾花的50个样本数据构成。其中的一个种类与另外两个种类是线性可分离的，后两个种类是非线性可分离的。

**四个属性：**

Sepal.Length（花萼长度），单位是cm;

Sepal.Width（花萼宽度），单位是cm;

Petal.Length（花瓣长度），单位是cm;

Petal.Width（花瓣宽度），单位是cm;

**三个种类：**

Iris Setosa（山鸢尾）；

Iris Versicolour（杂色鸢尾）；

Iris Virginica（维吉尼亚鸢尾）。

## databricks Runtime


Runtime是databricks 统一分析平台的一部分，官网描述如下：

> Accelerate innovation by unifying data science, engineering and business, with the Databricks Unified Analytics Platform, from the original creators of Apache Spark™.

Runtime的描述如下：

> Simplify operations and get up to 50x better performance with cloud-optimized Apache Spark™.

可以看到主要是基于云优化来简化操作并提升50倍以上的性能。

## [databricks Runtime版本与Spark版本的对应关系](https://docs.databricks.com/release-notes/runtime/databricks-runtime-ver.html#id6)

**Current Releases**

| Version | Spark Version | Release Date | Deprecation Announcement | Deprecation Date |
| ——- | ————- | ———— | ———————— | —————- |
| 5.2 | Spark 2.4 | Jan 24, 2019 | May 27, 2019 | Sep 30, 2019 |
| 5.1 | Spark 2.4 | Dec 18, 2018 | Apr 18, 2019 | Aug 19, 2019 |
| 5.0 | Spark 2.4 | Nov 08, 2018 | Mar 08, 2019 | Jul 08, 2019 |
| 4.3 | Spark 2.3 | Aug 10, 2018 | Dec 09, 2018 | Apr 09, 2019 |
| 4.2 | Spark 2.3 | Jul 09, 2018 | Nov 05, 2018 | Mar 05, 2019 |
| 3.5-LTS | Spark 2.2 | Dec 21, 2017 | Jan 02, 2019 | Jan 02, 2020 |

**Marked for Deprecation**

| Version | Spark Version | Release Date | Deprecation Announcement | Deprecation Date |
| ——- | ————- | ———— | ———————— | —————- |
| 4.3 | Spark 2.3 | Aug 10, 2018 | Dec 09, 2018 | Apr 09, 2019 |
| 4.2 | Spark 2.3 | Jul 09, 2018 | Nov 05, 2018 | Mar 05, 2019 |
| 3.5-LTS | Spark 2.2 | Dec 21, 2017 | Jan 02, 2019 | Jan 02, 2020 |

**Deprecated Releases**

| Version | Spark Version | Release Date | Deprecation Announcement | Deprecation Date |
| ————————- | ————- | ———— | ———————— | —————- |
| 4.1 | Spark 2.3 | May 17, 2018 | Sep 17, 2018 | Jan 17, 2019 |
| 4.0 | Spark 2.3 | Mar 01, 2018 | Jul 01, 2018 | Nov 01, 2018 |
| 3.4 | Spark 2.2 | Nov 20, 2017 | Mar 31, 2018 | Jul 30, 2018 |
| 3.3 | Spark 2.2 | Oct 04, 2017 | Mar 31, 2018 | Jul 30, 2018 |
| 3.2 | Spark 2.2 | Sep 05, 2017 | Jan 30, 2018 | Apr 30, 2018 |
| 3.1 | Spark 2.2 | Aug 04, 2017 | – | Oct 30, 2017 |
| 3.0 | Spark 2.2 | Jul 11, 2017 | – | Sep 05, 2017 |
| Spark 2.1 (Auto Updating) | Spark 2.1 | Dec 22, 2016 | Mar 31, 2018 | Jul 30, 2018 |
| Spark 2.1.1-db6 | Spark 2.1 | Aug 03, 2017 | Mar 31, 2018 | Jul 30, 2018 |
| Spark 2.1.1-db5 | Spark 2.1 | May 31, 2017 | – | Aug 03, 2017 |
| Spark 2.1.1-db4 | Spark 2.1 | Apr 25, 2017 | Mar 31, 2018 | Jul 30, 2018 |
| Spark 2.0 (Auto Updating) | Spark 2.0 | Jul 26, 2016 | Jan 30, 2018 | Apr 30, 2018 |
| Spark 2.0.2-db4 | Spark 2.0 | Mar 24, 2017 | Jan 30, 2018 | Apr 30, 2018 |
| Spark 1.6.3-db2 | Spark 1.6 | Mar 24, 2017 | Jan 30, 2018 | Jun 30, 2018 |

# 参考文献

1. https://docs.databricks.com/spark/latest/spark-sql/language-manual/analyze-table.html
2. https://docs.databricks.com/spark/latest/spark-sql/language-manual/describe-table.html
3. https://docs.databricks.com/spark/latest/spark-sql/cbo.html
4. https://docs.databricks.com/release-notes/runtime/databricks-runtime-ver.html#versioning
5. https://blog.csdn.net/Albert201605/article/details/82313139
6. https://archive.ics.uci.edu/ml/datasets/Iris
